On-Prem Cross Cluster Search Setup Guide

Set up bidirectional Cross-Cluster Search (CCS) between any number of OpenSearch clusters behind HAProxy with mutual TLS (mTLS).

Overview

Cross-Cluster Search (CCS) allows an OpenSearch cluster to execute search queries against one or more remote clusters as if they were a single cluster. This guide covers setting up bidirectional CCS between any number of OpenSearch clusters behind HAProxy with mutual TLS (mTLS).

What is Cross-Cluster Search?

CCS enables a coordinating cluster to fan out search requests to one or more remote clusters and aggregate the results transparently. A query like

GET agilesec-east:agilesec.kf-agilesec_com.v3.event-x509/_search

runs from cluster-a but returns results from cluster-b's index. Multiple clusters can be queried simultaneously:

GET agilesec-east:agilesec.kf-agilesec_com.v3.event-x509,agilesec-central:agilesec.kf-agilesec_com.v3.event-x509/_search

Use Cases

• Multi-region search: Query data across geographic regions from a single endpoint

• Disaster recovery: Read from a secondary cluster when the primary is degraded

• Data isolation: Keep cluster data separate for compliance while allowing unified search

Architecture

Traffic between clusters flows through HAProxy in proxy mode over port 9301 with mTLS. Every cluster connects to every other cluster. Each CCS cluster acts as both a local cluster and a remote cluster depending on where the query originates.

Proxy Connection Mode

This guide uses proxy mode because clusters are behind HAProxy. In proxy mode, all traffic flows through a single address and OpenSearch never tries to discover individual nodes behind it. Sniff mode (the default) requires direct network access to all nodes and does not work through a load balancer.

Prerequisites

• All clusters are running OpenSearch 2.x

• HAProxy is configured with mode tcp on port 9301 on each cluster

• Each cluster has its own root CA or shares one

  • Note: If all clusters share a CA, skip the CA bundle steps

• Node certificates use a wildcard pattern e.g. CN=*.your-domain.internal

• Each cluster's node certs are distinguishable by a DN attribute (e.g. ST=, O=, or OU=)

Example Cluster Topology

The steps below use these placeholder values. Replace them with your actual values.

Node topology (per cluster)

CCS Configuration Steps

These configuration steps use two clusters – cluster-a and cluster-b – as a working example with placeholder values. Substitute your own cluster names, node addresses, HAProxy endpoints, and certificate DNs throughout. The same process applies when connecting three, four, or more clusters.

Step 1: Setup HA Proxy

HA proxy on frontend must be setup to proxy OpenSearch transport traffic.

1. On node frontend-1, edit file <installation directory>/services/haproxy/haproxy.cfg

2. Add an HA proxy frontend configuration to listen on OpenSearch transport port. For this documentation we will use port 9301 as an example; however, any available port can be selected instead.

frontend fe_opensearch_transport
    bind frontend-1.kf-agilesec.internal:9301
    mode tcp
    option tcplog
    default_backend opensearch_transport_backend

2. Add an HA proxy backend to route traffic from 9301 to all OpenSearch backend nodes

backend opensearch_transport_backend
    mode tcp
    balance roundrobin
    default-server inter 5s fastinter 2s downinter 10s fall 3 rise 2
    server os1 backend-1.kf-agilesec.internal:9300 track opensearch_internal_backend/ois1
    server os2 backend-2.kf-agilesec.internal:9300 track opensearch_internal_backend/ois2

3. Restart HA Proxy

4. Test to make sure port 9301 is reachable through external FQDN of the other clusters.

From agilesec-a cluster:

nc -zv <agilesec-b external FQDN> 9301

Example

nc -zv agilesec.us-east-1.kf-agilesec.com 9301

From agilesec-b cluster:

nc -zv <agilesec-a external FQDN> 9301

Example

nc -zv agilesec.us-west-1.kf-agilesec.com 9301

Scaling to more clusters

For three or more clusters, each cluster’s external FQDN on port 9301 must be reachable by all nodes on other clusters.

# From agilesec-a
nc -zv <agilesec-b external FQDN> 9301
nc -zv <agilesec-c external FQDN> 9301

# From agilesec-b
nc -zv <agilesec-a external FQDN> 9301
nc -zv <agilesec-c external FQDN> 9301

# from agilesec-c
nc -zv <agilesec-a external FQDN> 9301
nc -zv <agilesec-b external FQDN> 9301

Step 2: Combine CA Bundles

When using separate CAs, each cluster must trust every other cluster's CA. Every cluster's CA bundle must contain the root CA of every other cluster it connects to.

Create a combined CA bundle on each cluster containing all CAs in the mesh.

Two-cluster example

1. On cluster agilesec-a 's backend-1 node, copy agilesec-rootca-cert.pem from agilesec-b cluster to <agilesec-a-installation-dir>/temp/agilesec-b-agilesec-rootca-cert.pem

2. Create agilesec-combined-rootca-cert.pem:

# Create combined bundle
INSTALL_DIR=<installer-dir>
cd $INSTALL_DIR/services/opensearch/config/certs
cat agilesec-rootca-cert.pem \
    $INSTALL_DIR/temp/agilesec-b-agilesec-rootca-cert.pem \
    > agilesec-combined-rootca-cert.pem

3. Copy agilesec-combined-rootca-cert.pem to all nodes on agilesec-a cluster.

4. On cluster agilesec-b’s backend-1 node, copy agilesec-rootca-cert.pem from agilesec-a cluster to <agilesec-b-installation-dir>/temp/agilesec-a-agilesec-rootca-cert.pem

5. Create agilesec-combined-rootca-cert.pem

# Create combined bundle
INSTALL_DIR=<installer-dir>
cd $INSTALL_DIR/services/opensearch/config/certs
cat agilesec-rootca-cert.pem \
    $INSTALL_DIR/temp/agilesec-a-agilesec-rootca-cert.pem \
    > agilesec-combined-rootca-cert.pem

6. Copy agilesec-combined-rootca-cert.pem to <installer-dir>/services/opensearch/config/certs on all nodes on agilesec-b cluster.

Scaling to more clusters

For three or more clusters, each bundle must include all CAs. The simplest approach is to build one master bundle and distribute it to all clusters:

# Build a single bundle with all CAs
cat ca-a.pem ca-b.pem ca-c.pem > /tmp/agilesec-combined-rootca-cert.pem

# Deploy the same bundle to every node on every cluster

Step 3: Update opensearch.yml on Each Cluster

Repeat these step for each cluster.

Data nodes (backend-1, backend-2)

Edit <installation dir>/services/opensearch/config/opensearch.yml.

1. Add remote_cluster_client to node roles:

node.roles: [cluster_manager, data, ingest, remote_cluster_client]

2. Add one node_dn entry per cluster. Check the value in each cluster’s opensearch.yml plugins.security.nodes_dn:

plugins.security.nodes_dn:
  - "<agilesec-a-node-dn>"
  - "<agilesec-b-node-dn>"
  # Add one entry per additional cluster

Example:

plugins.security.nodes_dn:
  - "CN=*.kf-agilesec.internal,OU=Server,O=Keyfactor,ST=California,C=US"
  - "CN=*.kf-agilesec.internal,OU=Server,O=Keyfactor,ST=Ohio,C=US"

3. Add one cluster.remote block per remote cluster:

cluster.remote.agilesec-b.mode: proxy
cluster.remote.agilesec-b.proxy_address: "<agilesec-b external FQDN>:9301"
# Add one block per additional remote cluster

Example:

cluster.remote.agilesec-east.mode: proxy
cluster.remote.agilesec-east.proxy_address: "agilesec.us-west-1.kf-agilesec.com"

4. Update plugins.security.ssl.transport.pemtrustedcas_filepath to point to agilesec-combined-rootca-cert.pem:

plugins.security.ssl.transport.pemtrustedcas_filepath: "certs/agilesec-combined-rootca-cert.pem"

Dedicated manager nodes (frontend-1)

Edit <installation dir>/services/opensearch/config/opensearch.yml. Same as backend nodes but without data and ingest in node roles:

1. Add remote_cluster_client to node roles:

   node.roles: [cluster_manager, remote_cluster_client]


2. Add one node_dn entry per cluster. Check the value in each cluster’s opensearch.yml plugins.security.nodes_dn:

   plugins.security.nodes_dn:
     - "<agilesec-a-node-dn>"
     - "<agilesec-b-node-dn>"
     # Add one entry per additional cluster


3. Add one cluster.remote block per remote cluster:

   cluster.remote.agilesec-b.mode: proxy
   cluster.remote.agilesec-b.proxy_address: "<agilesec-b external FQDN>:9301"
   # Add one block per additional remote cluster


Example

node.roles: [cluster_manager, remote_cluster_client]

plugins.security.nodes_dn:
  - "CN=*.kf-agilesec.internal,OU=Server,O=Keyfactor,ST=California,C=US"
  - "CN=*.kf-agilesec.internal,OU=Server,O=Keyfactor,ST=Ohio,C=US"

cluster.remote.agilesec-east.mode: proxy
cluster.remote.agilesec-east.proxy_address: "agilesec.us-east-1.kf-agilesec.com:9301"

Scaling to more clusters

Each cluster needs one cluster.remote block per remote cluster and one nodes_dn entry per remote cluster's node cert DN. For a three-cluster mesh, each cluster's config would look like:

cluster.remote.agilesec-b.mode: proxy
cluster.remote.agilesec-b.proxy_address: "<cluster-b-haproxy>"
cluster.remote.agilesec-c.mode: proxy
cluster.remote.agilesec-c.proxy_address: "<cluster-c-haproxy>"

plugins.security.nodes_dn:
  - "<agilesec-a-node-dn>"
  - "<agilesec-b-node-dn>"
  - "<agilesec-c-node-dn>"

GET <name>:agilesec.kf-agilesec_com.v3.event-x509/_search

Step 4: Restart Clusters

Restart all clusters after updating configs. When restarting multiple clusters, do them one at a time. Within each cluster restart nodes in this order to avoid disruption:

1. frontend-1 (dedicated manager)

2. backend-1

3. backend-2

Wait for each node to fully rejoin the cluster before restarting the next.

bash /home/ec2-user/351/scripts/manage.sh restart opensearch

Step 5: Verify OpenSearch

1. Login as platform admin on agilesec-a cluster and go to Advanced Dashboard.

2. In Advanced Dashboard, go to Dev Tools and run the following queries:

Check all nodes are up

GET _cat/nodes?v&h=name,ip,node.role

All nodes should appear with r in the node.role column confirming remote_cluster_client is active.

Example:

name                  ip            node.role
opensearch-backend-2  10.100.220.59 dimr
opensearch-backend-1  10.100.220.56 dimr
opensearch-frontend-1 10.100.220.53 mr

Check remote connections

GET _remote/info

Expected response showing all remote clusters connected:

{
  "cluster-b": {
    "connected": true,
    "mode": "proxy",
    "proxy_address": "<agilesec-b cluster external FQDN>:9301",
    "num_proxy_sockets_connected": 0
  }
}

Test CCS queries

Count documents in a remote index:

GET agilesec-b:agilesec.kf-agilesec_com.v3.event-x509/_count

Search across both clusters simultaneously:

GET agilesec.kf-agilesec_com.v3.event-x509,agilesec-b:agilesec.kf-agilesec_com.v3.event-x509/_search
{
  "query": { "match_all": {} }
}

Step 6: Update Advanced Dashboards

Advanced Dashboards need to be updated to use CCS.

1. Log in to Agilesec UI as a Platform Admin and go to Advanced Dashboards.

2. Go to Dev tools.

Update event-* Index pattern

1. Run following query to get index pattern id.

GET .kibana/_search
{
  "query": {
    "bool": {
      "must": [
        { "term": { "type": "index-pattern" } },
        { "match_phrase": { "index-pattern.title": "agilesec.<org_domain>.v3.event-*" } }
      ]
    }
  },
  "_source": ["index-pattern.title"]
}

2. copy _id.

3. Update index pattern for event-* to include all other regions.

POST .kibana/_update/<_id from step 3>
{
  "doc": {
    "index-pattern": {
      "title": "agilesec.<org domain>.v3.event-*,agilesec-*:agilesec.<org domain>.v3.event-*"
    }
  }
}

4. Refresh Field List for event-* Index Pattern

   1. Navigate to Settings → Settings and Setup → Index Patterns.

   2. Select the event-* index pattern.

   3. Click Refresh Field List.

Update alert-* Index Pattern

1. Run the following query to get the index pattern id.

GET .kibana/_search
{
  "query": {
    "bool": {
      "must": [
        { "term": { "type": "index-pattern" } },
        { "match_phrase": { "index-pattern.title": "agilesec.<org domain>.v3.alert-*" } }
      ]
    }
  },
  "_source": ["index-pattern.title"]
}

2. copy _id

3. Update index pattern for alert-* to include all other regions.

POST .kibana/_update/<_id from step 3>
{
  "doc": {
    "index-pattern": {
      "title": "agilesec.<org domain>.v3.alert-*,agilesec-*:agilesec.<org domain>.v3.alert-*"
    }
  }
}

4. Refresh Field List for alert-* Index Pattern

   1. Navigate to Settings → Settings and Setup → Index Patterns.

   2. Select the alert-* index pattern.

   3. Click Refresh Field List.

Step 7: Verify Advanced Dashboard

1. Go to Advanced Dashboard and check any dashboard to see if it shows data from other regions.

2. Add following filter to any dashboard to restrict data for a specific region


Adding a New Cluster to an Existing Mesh

When adding a new cluster to an already running CCS mesh, the following changes are required on all existing clusters.

Since the CA bundle update requires a restart anyway, it is generally cleaner to add all settings in opensearch.yml and do a single restart.

Adding cluster.remote via API only (no restart needed):

PUT _cluster/settings
{
  "persistent": {

    "cluster.remote.cluster-c.mode": "proxy",
    "cluster.remote.cluster-c.proxy_address": "<agilesec-c external FQDN>:9301"
  }
}

Key Settings Reference

Troubleshooting

GET _remote/info returns {}

• Verify remote_cluster_client is in node.roles on all nodes

• Check which config file OpenSearch is actually using: ps aux | grep opensearch | grep path.conf

• Confirm HAProxy port is reachable from the node: (echo > /dev/tcp/<haproxy-host>/9301) && echo "OPEN" || echo "CLOSED"

• Check for conflicting persistent API settings: GET _cluster/settings?flat_settings=true

SSL handshake / connection reset errors

• CA bundle is missing the remote cluster's CA – verify with: openssl verify -CAfile rootca-cert.pem rootca-cert.pem

• CA bundle may be corrupted (incomplete PEM) – copy a known good bundle from another node and verify

• Set plugins.security.ssl.transport.enforce_hostname_verification: false if node certs use internal hostnames but HAProxy uses public hostnames

CCS returns index_not_found

• OpenSearch Security masks permission errors as 404 – this is usually a nodes_dn mismatch

• Verify the remote cluster's node cert DN is listed in nodes_dn on the receiving cluster

• Check the receiving cluster's audit log for MISSING_PRIVILEGES entries when the query arrives

Connected but query returns no results

• Confirm the index exists on the remote cluster: log into the remote cluster and run GET _cat/indices?v

• The alias used in the query must exactly match the name configured in cluster.remote.<name>
